·Ultra-flat, space-saving design
·Stirring speed range: 15 - 1500 rpm
·Automatic rotation-reversing stirring for better mixing results
·PET work plate provides excellent chemical resistance
·Ultra silence and vibration-free
| SPECIFICATIONS | FlatSpin |
| Electrical Stirring position Max. stirring quantity[H2O] Max. magnetic bar[L] Motor type Motor rating input/output Speed range Speed display Work plate material Dimension of work plate Dimensions[W×D×H] Weight Protection class acc. DIN EN60529 Work environment | 100-120/200-240V, 50/60Hz, 5W 1 0.8L 40 mm DC motor 3 W 15-1500 rpm Button PET Φ90 mm 175×120×15 mm 0.3 kg IP65 5-40℃, 80%RH |
| TYPE | DESCRIPTION | POWER SUPPLY | P/N |
| FlatSpin | Ultra-flat Compact Magnetic Stirrer, PET work plate | Cn Plug, 220V/50Hz/60Hz Euro Plug, 200-240V/50Hz/60Hz UK Plug, 200-240V/50Hz/60Hz USA Plug, 100-120V/50Hz/60Hz | 4420-6001 4420-6002 4420-6003 4420-6004 |
