● Thermal gradient: program different temperatures across different areas of the heating block
● Excellent temperature control system
● Fast heating and cooling rate
● Consistent and uniform sealing across entire heating block
● 7 inch Large color touch panel screen for easy programming
| SPECIFICATIONS | TC1000-G | TC1000-S |
Sample Capacity Heating temperature range Lid temperature range Temperature display accuracy Temperature control accuracy[at 55℃] Temperature uniformity [at 55℃] Max. heating/cooling rate Gradient temperature setting range Gradient range Adapter block material Display Input User defined file system Power off protection Power supply Dimensions[W×D×H] Weight | 96×0.2 ml PCR tube, 8×12 PCR plate or 96 well plate 4-99℃ 50-100℃ 0.1℃ ±0.3℃ ＜0.3 ℃ 3 ℃/Sec 30-99℃ 1-42℃ Aluminum 7” 800× 480 LCD Touch panel 30 segments 99 cycle max. 16 folder and 16 files each folder max. yes 100-120V/200-240V,50/60Hz 280×370×250 mm 11 kg | 96×0.2 ml PCR tube, 8×12 PCR plate or 96 well plate 4-99℃ 50-100℃ 0.1℃ ±0.3℃ ＜0.3 ℃ 3 ℃/Sec -- -- Aluminum 7” 800× 480 LCD Touch panel 30 segments 99 cycle max. 16 folder and 16 files each folder max. yes 100-120V/200-240V,50/60Hz 280×370×250 mm 11 kg |
| TYPE | POWER SUPPLY | P/N |
| TC1000-G | Cn Plug, 100-240V/50Hz/60Hz Euro Plug, 100-240V/50Hz/60Hz UK Plug, 100-240V/50Hz/60Hz USA Plug, 100-240V/50Hz/60Hz | 4431-0001 4431-0002 4431-0003 4431-0004 |
| TYPE | POWER SUPPLY | P/N |
| TC1000-S | Cn Plug, 100-240V/50Hz/60Hz Euro Plug, 100-240V/50Hz/60Hz UK Plug, 100-240V/50Hz/60Hz USA Plug, 100-240V/50Hz/60Hz | 4431-1001 4431-1002 4431-1003 4431-1004 |
● Thermal gradient: program different temperatures across different areas of the heating block
● Excellent temperature control system
● Fast heating and cooling rate
● Consistent and uniform sealing across entire heating block
● 7 inch Large color touch panel screen for easy programming
| SPECIFICATIONS | TC1000-G | TC1000-S |
Sample Capacity Heating temperature range Lid temperature range Temperature display accuracy Temperature control accuracy[at 55℃] Temperature uniformity [at 55℃] Max. heating/cooling rate Gradient temperature setting range Gradient range Adapter block material Display Input User defined file system Power off protection Power supply Dimensions[W×D×H] Weight | 96×0.2 ml PCR tube, 8×12 PCR plate or 96 well plate 4-99℃ 50-100℃ 0.1℃ ±0.3℃ ＜0.3 ℃ 3 ℃/Sec 30-99℃ 1-42℃ Aluminum 7” 800× 480 LCD Touch panel 30 segments 99 cycle max. 16 folder and 16 files each folder max. yes 100-120V/200-240V,50/60Hz 280×370×250 mm 11 kg | 96×0.2 ml PCR tube, 8×12 PCR plate or 96 well plate 4-99℃ 50-100℃ 0.1℃ ±0.3℃ ＜0.3 ℃ 3 ℃/Sec -- -- Aluminum 7” 800× 480 LCD Touch panel 30 segments 99 cycle max. 16 folder and 16 files each folder max. yes 100-120V/200-240V,50/60Hz 280×370×250 mm 11 kg |
| TYPE | POWER SUPPLY | P/N |
| TC1000-G | Cn Plug, 100-240V/50Hz/60Hz Euro Plug, 100-240V/50Hz/60Hz UK Plug, 100-240V/50Hz/60Hz USA Plug, 100-240V/50Hz/60Hz | 4431-0001 4431-0002 4431-0003 4431-0004 |
| TYPE | POWER SUPPLY | P/N |
| TC1000-S | Cn Plug, 100-240V/50Hz/60Hz Euro Plug, 100-240V/50Hz/60Hz UK Plug, 100-240V/50Hz/60Hz USA Plug, 100-240V/50Hz/60Hz | 4431-1001 4431-1002 4431-1003 4431-1004 |
