·Touch and continuous operations
·Stepless speed regulation, speed range of 0-2500rpm
·Aluminium cast base, with vacuum suction feet, avoids unnecessary “walking”
·A variety of tube adapters are optional
·Fixed speed of 2500rpm and 3000rpm are available
| SPECIFICATIONS | MX-S |
| Electrical Mixing motion Orbital diameter Motor rating input/output Permissible on time Speed range Speed display Run type Dimensions[W×D×H] Weight Protection class acc. DIN EN60529 Work environment | 110-120/220-230V, 50 Hz/60HZ, 60W Orbital 4 mm 58/10 W 100% 0-2500 rpm Scale Continuous/ touch operation 127×160×130mm 3.5 kg IP 21 5－40 ℃, 80%RH |
| P/N | TYPE | POWER SUPPLY | |
| 4424-0001 4424-0002 4424-0003 4424-0004 | MX-S | Cn Plug, 220-230V/50Hz/60Hz Euro Plug, 220-230V/50Hz/60Hz UK Plug, 220-230V/50Hz/60Hz USA Plug, 110-120V/50Hz/60Hz | |
Accessories
| P/N | TYPE | DESCRIPTION | |||
| 4499-0021 4424-9900 4499-0022 4499-0023* 4499-0024* 4499-0025* 4499-0026* 4499-0027* 4499-0028 4424-9901 | VT1.1 VT1.2 VT1.3 VT1.3.1 VT1.3.2 VT1.3.3 VT1.3.4 VT1.3.5 VT1.3.6 VT1.3.7 | Standard top, for test tubes and small vessels up to diameter 30mm Tube holding rod used with VT1.3.1~VT1.3.5 Universal top plate, 100mm-plate attachment with rubber pad Tube adapter, for 48 holes test tubes, Ø6mm Tube adapter, for 18 holes test tubes, Ø10mm Tube adapter, for 12 holes test tubes, Ø12mm Tube adapter, for 8 holes test tubes, Ø16mm Tube adapter, for 8 holes test tubes, Ø20mm Platform pad, for <Ø99mm tubes and small vessels, used with VT1.3 Rubber vacuum suction foot | |||
*Just suitable for MX-S, used with VT1.2, VT1.3 under continuous operation
